DemGenTrout 1.2

;; DemGenTrout 1.2 (2012)
;;
;; Developed by
;; Beatrice M. Frank
;; Earth and Life Institute
;; Universite catholique de Louvain
;; Beatrice.Frank@gmail.com
;;
;; Last updated: September 2012

breed[ trout ]
breed[ dead ]
breed[ gone ]

;; trout state variables
trout-own[ sex genotype natal-stream week-of-birth week-of-birth2 ;; fixed
  current-stream age stage status body-length body-weight condition-factor num-offspring
  spawned? moved-to-spawn? returned? ]

;; gone trout state variables
gone-own[ sex genotype natal-stream week-of-birth week-of-birth2 ;; fixed
  current-stream age stage status body-length body-weight condition-factor num-offspring
  spawned? moved-to-spawn? returned? ]

;; dead trout state variables
dead-own[ sex genotype natal-stream week-of-birth week-of-birth2 ;; fixed
  current-stream age stage status body-length body-weight condition-factor num-offspring
  spawned? moved-to-spawn? returned? ]

;; stream state variables
patches-own [ stream flow temperature ]

globals[ week week-of-year month-of-year year
 ;; trout initialisation
 prop-C prop-L init-N
 prop-age0-C prop-age1-C prop-age2-C prop-age3-C
 prop-age0-L prop-age1-L prop-age2-L
 meanl-age0-C meanl-age0-L meanl-age1-C meanl-age1-L meanl-age2-C meanl-age2-L meanl-age3-C meanl-age3-L
 sdl-age0-C sdl-age0-L sdl-age1-C sdl-age1-L sdl-age2-C sdl-age2-L sdl-age3-C sdl-age3-L
 trdown-age0-C trdown-age0-L trdown-age1-C trdown-age1-L trdown-age2-C trdown-age2-L trdown-age3-C trdown-age3-L
 trup-age0-C trup-age0-L trup-age1-C trup-age1-L trup-age2-C trup-age2-L trup-age3-C trup-age3-L
 meanl-birth-C sdl-birth-C meanl-birth-L sdl-birth-L trdown-C trup-C trdown-L trup-L
 mean-bcf-C sd-bcf-C mean-bcf-L sd-bcf-L
 propC-inL
 ;; stream input data
 streamC-discharge streamL-discharge streamC-temperature streamL-temperature
 mean-dischargeC sd-dischargeC mean-dischargeL sd-dischargeL
 mean-temperatureC sd-temperatureC mean-temperatureL sd-temperatureL
 max-dischargeC max-dischargeL

 ;; survival parameters
 streamC-age0-survival streamC-age1-survival streamC-age2-survival streamC-age3-survival
 streamL-age0-survival streamL-age1-survival streamL-age2-survival streamL-age3-survival
 streamC-age0-survival-list streamC-age1-survival-list streamC-age2-survival-list streamC-age3-survival-list
 streamL-age0-survival-list streamL-age1-survival-list streamL-age2-survival-list streamL-age3-survival-list
; predation-factor
 ;; growth parameters
 streamC-parK streamL-parK
 streamC-max-length streamC-parA streamC-parB streamL-max-length streamL-parA streamL-parB
 ;; spawning parameters
; spawn-start spawn-end moved-prop spawn-mean-length spawn-mean-cond
 spawn-sd-length spawn-sd-cond spawn-min-age
 spawn-mean-temperature spawn-sd-temperature spawn-mean-flow spawn-sd-flow
 streamC-capacity offprod offprod-min-length offprod-max-length offprod-min
 offspringC-varA offspringC-varB offspringL-varA offspringL-varB
; offprodC-max offprodL-max
 length-heritability
 ;; hatching parameters
 hatch-start hatch-end
 ;; downstream movement parameters
; move-start move-end move-min-age move-max-age
 move-mean-length move-sd-length
 move-age1-prob move-age2-prob
; move-age1-varB move-age1-varA move-age2-varB move-age2-varA
 move-mean-temperature move-sd-temperature move-mean-flow move-sd-flow
 ;; leaving stream L forever parameters
 leaving-propC leaving-propL

 out-year out-month out-week
 ]

to setup
  clear-all
  no-display
  ;; controlling the random numbers
  random-seed 1223251200

  ;; first week of the year = 1st to 7th October included
  set week 1
  set week-of-year 1
  set month-of-year 1
  set year 1

  import-world "DemGenTrout-world.csv"
  reset-ticks
end

to restore-defaults
  ;; restore the default parameters
  ;;; input parameters ;;;
  file-open "init-params.txt"
  ;; weekly survival rates for trout in stream C
  if file-read = "streamC.age0.survival" [set streamC-age0-survival file-read]
  if file-read = "streamC.age1.survival" [set streamC-age1-survival file-read]
  if file-read = "streamC.age2.survival" [set streamC-age2-survival file-read]
  if file-read = "streamC.age3.survival" [set streamC-age3-survival file-read]
  ;; weekly survival rates for trout in stream L
  if file-read = "streamL.age0.survival" [set streamL-age0-survival file-read]
  if file-read = "streamL.age1.survival" [set streamL-age1-survival file-read]
  if file-read = "streamL.age2.survival" [set streamL-age2-survival file-read]
  if file-read = "streamL.age3.survival" [set streamL-age3-survival file-read]
  if file-read = "predation.factor" [set predation-factor file-read]
  ;; growth parameters
  if file-read = "streamC.parK" [set streamC-parK file-read]
  if file-read = "streamL.parK" [set streamL-parK file-read]
  if file-read = "streamC.max.length" [set streamC-max-length file-read]
  if file-read = "streamL.max.length" [set streamL-max-length file-read]
  if file-read = "streamC.parA" [set streamC-parA file-read]
  if file-read = "streamL.parA" [set streamL-parA file-read]
  if file-read = "streamC.parB" [set streamC-parB file-read]
  if file-read = "streamL.parB" [set streamL-parB file-read]
  ;; spawning parameters
  if file-read = "spawn.start" [set spawn-start file-read]
  if file-read = "spawn.end" [set spawn-end file-read]
  if file-read = "spawn.min.age" [set spawn-min-age file-read]
  if file-read = "spawn.mean.length" [set spawn-mean-length file-read]
  if file-read = "spawn.sd.length" [set spawn-sd-length file-read]
  if file-read = "spawn.mean.cond" [set spawn-mean-cond file-read]
  if file-read = "spawn.sd.cond" [set spawn-sd-cond file-read]
  if file-read = "moved.prop" [set moved-prop file-read]
  if file-read = "spawn.mean.flow" [set spawn-mean-flow file-read]
  if file-read = "spawn.sd.flow" [set spawn-sd-flow file-read]
  if file-read = "streamC.capacity" [set streamC-capacity file-read]
  if file-read = "offprod.min.length" [set offprod-min-length file-read]
  if file-read = "offprod.max.length" [set offprod-max-length file-read]
  if file-read = "offprod.min" [set offprod-min file-read]
  if file-read = "offprodC.max" [set offprodC-max file-read]
  if file-read = "offprodL.max" [set offprodL-max file-read]
  if file-read = "length.heritability" [set length-heritability file-read]
  ;; hatching parameters
  if file-read = "hatch.start" [set hatch-start file-read]
  if file-read = "hatch.end" [set hatch-end file-read]
  ;; downstream movement parameters
  if file-read = "move.start" [set move-start file-read]
  if file-read = "move.end" [set move-end file-read]
  if file-read = "move.min.age" [set move-min-age file-read]
  if file-read = "move.max.age" [set move-max-age file-read]
  if file-read = "move.mean.length" [set move-mean-length file-read]
  if file-read = "move.sd.length" [set move-sd-length file-read]
  if file-read = "move.age1.varA" [set move-age1-varA file-read]
  if file-read = "move.age1.varB" [set move-age1-varB file-read]
  if file-read = "move.age2.varA" [set move-age2-varA file-read]
  if file-read = "move.age2.varB" [set move-age2-varB file-read]
  if file-read = "move.mean.temperature" [set move-mean-temperature file-read]
  if file-read = "move.sd.temperature" [set move-sd-temperature file-read]
  if file-read = "move.mean.flow" [set move-mean-flow file-read]
  if file-read = "move.sd.flow" [set move-sd-flow file-read]
  ;; leaving streamL forever parameters
  if file-read = "leaving.propC" [set leaving-propC file-read]
  if file-read = "leaving.propL" [set leaving-propL file-read]
  file-close

  set C-age0-survival 0.39 set C-age1-survival 0.37 set C-age2-survival 0.85 set C-age3-survival 0.70
  set L-age0-survival 0.38 set L-age1-survival 0.74 set L-age2-survival 0.87 set L-age3-survival 0.69
end

to set-parameters
  ;; weekly survival rates for trout in stream C
  file-open "streamC-age0-survival.txt"
  set streamC-age0-survival-list file-read file-close
  file-open "streamC-age1-survival.txt"
  set streamC-age1-survival-list file-read file-close
  file-open "streamC-age2-survival.txt"
  set streamC-age2-survival-list file-read file-close
  file-open "streamC-age3-survival.txt"
  set streamC-age3-survival-list file-read file-close
  ;; weekly survival rates for trout in stream L
  file-open "streamL-age0-survival.txt"
  set streamL-age0-survival-list file-read file-close
  file-open "streamL-age1-survival.txt"
  set streamL-age1-survival-list file-read file-close
  file-open "streamL-age2-survival.txt"
  set streamL-age2-survival-list file-read file-close
  file-open "streamL-age3-survival.txt"
  set streamL-age3-survival-list file-read file-close

  let seq (list 0.00 0.01 0.02 0.03 0.04 0.05 0.06 0.07 0.08 0.09
                     0.10 0.11 0.12 0.13 0.14 0.15 0.16 0.17 0.18 0.19
                     0.20 0.21 0.22 0.23 0.24 0.25 0.26 0.27 0.28 0.29
                     0.30 0.31 0.32 0.33 0.34 0.35 0.36 0.37 0.38 0.39
                     0.40 0.41 0.42 0.43 0.44 0.45 0.46 0.47 0.48 0.49
                     0.50 0.51 0.52 0.53 0.54 0.55 0.56 0.57 0.58 0.59
                     0.60 0.61 0.62 0.63 0.64 0.65 0.66 0.67 0.68 0.69
                     0.70 0.71 0.72 0.73 0.74 0.75 0.76 0.77 0.78 0.79
                     0.80 0.81 0.82 0.83 0.84 0.85 0.86 0.87 0.88 0.89
                     0.90 0.91 0.92 0.93 0.94 0.95 0.96 0.97 0.98 0.99 1.00)
  let index (list 0  1  2  3  4  5  6  7  8  9 10 11 12 13 14 15 16 17 18 19
                 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39
                 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59
                 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79
                 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
                 100)

  (foreach seq index
    [
      if C-age0-survival = ?1 [set streamC-age0-survival item ?2 streamC-age0-survival-list]
      if C-age1-survival = ?1 [set streamC-age1-survival item ?2 streamC-age1-survival-list]
      if C-age2-survival = ?1 [set streamC-age2-survival item ?2 streamC-age2-survival-list]
      if C-age3-survival = ?1 [set streamC-age3-survival item ?2 streamC-age3-survival-list]
      if L-age0-survival = ?1 [set streamL-age0-survival item ?2 streamL-age0-survival-list]
      if L-age1-survival = ?1 [set streamL-age1-survival item ?2 streamL-age1-survival-list]
      if L-age2-survival = ?1 [set streamL-age2-survival item ?2 streamL-age2-survival-list]
      if L-age3-survival = ?1 [set streamL-age3-survival item ?2 streamL-age3-survival-list]
    ])
end

;;;;;;;;;;;;;;;;;;;;;;;;;;;;; SCHEDULING ;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

to go
  no-display
  tick
  if ticks = 1820 [ user-message "Input data are only available for 35 years."  stop ]
  if count trout with [ current-stream = "C" ] = 0 [ user-message (word "There are no trout in the brook at year " year ".") stop ]
  ;; a year = 52 weeks
  set week-of-year (week mod 52) + 1
  set month-of-year (int(week-of-year / 4.5) mod 52) + 1
  set year (int(week / 52)) + 1 ; mod 52

  ;; each week

;-- 1. Update stream hydrological conditions ----------------------------------------------------------

  ask patches [ update-stream-conditions ]

;-- 2. Kill trout in each stream ----------------------------------------------------------------------

  ask trout [ trout-die ]

;-- 3. Update trout length, weight and condition factor -----------------------------------------------

  ask trout [ trout-grow ]

;-- 4. Reproduce trout in each stream -----------------------------------------------------------------

  ;; spawning time window: duration = 11 weeks
  if week-of-year >= spawn-start and week-of-year <= spawn-end
  [
    ;--- 4.1. Identify candidate spawners ---;
    ask trout [ trout-become-candidate-spawners ]
;    ;; select some of the candidate spawners born in stream L in order to make them reproduce in C
;    let candidate-spawners-streamL trout with [ status = "candidate-spawner" and current-stream = "L"
;      and natal-stream = "L" and not moved-to-spawn? ]
;    while [ (count trout with [status = "selected-candidate-spawner"]) < (moved-prop * count candidate-spawners-streamL) ]
;    [ ask one-of candidate-spawners-streamL [ set status "selected-candidate-spawner" ] ]
;
;    ;--- 4.2. Move candidate spawners upstream ---;
;    ask trout [ trout-move-to-spawn ]

    ;; adapt offspring production if abundance in C is strictly higher than streamC-capacity
    ifelse count trout with [ current-stream = "C" ] > streamC-capacity
    [ set offprodC-max offprod / 10 ]
    [ set offprodC-max offprod ]

    ;--- 4.3. Produce offspring in each stream ---;
    trout-spawn-in-streamC
    trout-spawn-in-streamL
  ]

;-- 5. Increment trout age and update stage -----------------------------------------------------------

  if week-of-year = (hatch-start - 1) ;; one week before hatching
  [
    ask trout [ trout-update-age ]
    ask trout with [age > 6] [die!] ;; trout die at age 7
  ]

;-- 6. Reveal offspring -------------------------------------------------------------------------------

  ;; hatching time window: duration = 11 weeks
  if week-of-year >= hatch-start and week-of-year <= hatch-end
  [ (foreach sort trout with [age = -1]
      [ ask ?
        [
          if (week-of-year - week-of-birth) = (hatch-start - spawn-start) ;; delay = 10 weeks
          [ set hidden? false set age 0 ]
        ]])
  ]

;-- 7. Move trout of stream C downstream ----------------------------------------------------------

  ;; migration time window: duration = 25 weeks
  if week-of-year >= move-start and week-of-year <= move-end
  [
    ;--- 7.1. Identify candidate migrants among juveniles ---;
    ask trout [ trout-become-candidate-migrants ]

    ;--- 7.2. Update movement probabilities ---;
    update-move-age1-prob
    update-move-age2-prob

    ;--- 7.3. Move candidate migrants ---;
    ask trout [ trout-move-downstream ]
  ]

;-- 8. Move upswimming spawners back to stream L -----------------------------------------------------

  if week-of-year = (spawn-end + 1) ;; the week after the spawning process
  [
    ask trout [ trout-move-back ]
  ]

;-- 9. Remove young trout of stream L from the system ------------------------------------------------

  ;; at the end of the year
  if week-of-year = 52
  [
    ;; some juveniles born in C and living in stream L do not settle and go elsewhere
    let bornC-in-streamL trout with [current-stream = "L" and natal-stream = "C" and status = "migrant"]
    let bornC-leaving (leaving-propC * count bornC-in-streamL)
    ask n-of bornC-leaving bornC-in-streamL [ leave-streamL ]
    ;; some juveniles born in L and living in stream L do not settle and go elsewhere
    let bornL-in-streamL trout with [current-stream = "L" and natal-stream = "L" and (age = 1 or age = 2)]
    let bornL-leaving (leaving-propL * count bornL-in-streamL)
    ask n-of bornL-leaving bornL-in-streamL [ leave-streamL ]
  ]

; Trout reset --------------------------------------------------------------------------------------

  ;; at the end of the year
  if week-of-year = 52
  [
    ;; reset trout status and boolean state variables
    ask trout [ set status "non-spawner" set moved-to-spawn? false set spawned? false set returned? false ]
    ;; kill all hidden turtles
    ask gone [die]
    ask dead [die]
  ]

; Increment the week -------------------------------------------------------------------------------

  set week week + 1
end

;;;;;;;;;;;;;;;;;;;;;;;;;;; STREAM PROCEDURE ;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

;; update water temperature and flow of each stream

to update-stream-conditions
  ifelse ticks < (6 * 52)
  ;; first 6 years (2004 to 2009)
  [
    ifelse stream = "C"
    [
      set flow item week streamC-discharge
      set temperature item week streamC-temperature
    ]
    [
      set flow item week streamL-discharge
      set temperature item week streamL-temperature
    ]
  ]
  ;; next years (2010 to 2038)
  [
    ifelse stream = "C"
    [
      set flow min (list max-dischargeC (item week streamC-discharge + random-lognormal mean-dischargeC sd-dischargeC))
      set temperature (item week streamC-temperature + random-normal mean-temperatureC sd-temperatureC)
    ]
    [
      set flow min (list max-dischargeL (item week streamL-discharge + random-lognormal mean-dischargeL sd-dischargeL))
      set temperature (item week streamL-temperature + random-normal mean-temperatureL sd-temperatureL)
    ]
  ]
end

;;;;;;;;;;;;;;;;;;;;;;;;;; TROUT PROCEDURES ;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

;; trout mortality

to trout-die
  ;; in stream C
  if stage = "fry" and current-stream = "C" [if random-float 1 > ((item week-of-year streamC-age0-survival) ^ (1 / 52)) [die!]]
  if stage = "juvenile" and age = 1 and current-stream = "C" [if random-float 1 > ((item week-of-year streamC-age1-survival) ^ (1 / 52)) [die!]]
  if stage = "juvenile" and age = 2 and current-stream = "C" [if random-float 1 > ((item week-of-year streamC-age2-survival) ^ (1 / 52)) [die!]]
  if stage = "adult" and age < 6 and current-stream = "C" [if random-float 1 > ((item week-of-year streamC-age3-survival) ^ (1 / 52)) [die!]]
  if week-of-year >= spawn-start and week-of-year <= spawn-end and moved-to-spawn? = true and current-stream = "C"
   [if random-float 1 > (((item week-of-year streamC-age3-survival) / predation-factor) ^ (1 / (spawn-end - spawn-start))) [die!]]
  ;; in stream L
  if stage = "fry" and current-stream = "L" [if random-float 1 > ((item week-of-year streamL-age0-survival) ^ (1 / 52)) [die!]]
  if stage = "juvenile" and age = 1 and current-stream = "L" [if random-float 1 > ((item week-of-year streamL-age1-survival) ^ (1 / 52)) [die!]]
  if stage = "juvenile" and age = 2 and current-stream = "L" [if random-float 1 > ((item week-of-year streamL-age2-survival) ^ (1 / 52)) [die!]]
  if stage = "adult" and age < 6 and current-stream = "L" [if random-float 1 > ((item week-of-year streamL-age3-survival) ^ (1 / 52)) [die!]]
end

;; individual growth

to trout-grow
  ifelse current-stream = "C"
  [
    ;; von Bertalanffy growth equation for trout in stream C
    set body-length (body-length + (streamC-parK * (streamC-max-length - body-length)))
    let healthy-weight (streamC-parA * ((body-length) ^ streamC-parB)) ;; weight-length regression
    set body-weight (condition-factor * healthy-weight)
  ]
  [
    ;; von Bertalanffy growth equation for trout in stream L
    set body-length (body-length + (streamL-parK * (streamL-max-length - body-length)))
    let healthy-weight (streamL-parA * ((body-length) ^ streamL-parB)) ;; weight-length regression
    set body-weight (condition-factor * healthy-weight)
  ]
  set condition-factor max (list 0.5 (condition-factor + (- 0.008 + random-float 0.016)))
  ;; test for negative length and negative weight
  if body-length < 0 [ user-message "Negative fish length" ]
  if body-weight < 0 [ user-message "Negative fish weight" ]
end

to die!
  set breed dead
  hide-turtle
end

;; identification of candidate spawners

to trout-become-candidate-spawners
  if age >= spawn-min-age and status != "spawner" and not moved-to-spawn?
  [ if random-normal spawn-mean-length spawn-sd-length < body-length and
    random-normal spawn-mean-cond spawn-sd-cond < condition-factor
    [ set status "candidate-spawner" ] ]
end

;; movement to stream C for reproduction

to trout-move-to-spawn
 let temperature-streamL [temperature] of one-of patches with [ stream = "L" ]
 let flow-streamL [flow] of one-of patches with [ stream = "L" ]
 ;; spawners born in C or in L move to C
 if (status = "candidate-spawner" and not moved-to-spawn? and current-stream = "L" and natal-stream = "C")
   or (status = "selected-candidate-spawner" and not moved-to-spawn?)
 [ if random-lognormal spawn-mean-flow spawn-sd-flow < flow-streamL
   [ set current-stream "C" set xcor 1 set moved-to-spawn? true set status "candidate-spawner" ] ]
end

;; update trout age and stage

to trout-update-age
  set age age + 1
  trout-update-stage
end

;; update trout stage: fry, juvenile, adult

to trout-update-stage
  if age < 1 [ set stage "fry" stop ]
  if age >= 1 and age <= 2 [ set stage "juvenile"stop ]
  if age > 2 [ set stage "adult" stop ]
end

;; reproduction

to trout-spawn-in-streamC
  let spawners trout with [ status = "candidate-spawner" or status = "spawner" and current-stream = "C" ]
  ifelse count spawners < 2
  [ stop ]
  [
    ;; length of parents when born (VBLF backwards)
    let born-length-parents VBLF-reverse spawners
    ;; mean and variance of length of parents when born
    if length born-length-parents < 2 [ stop ]
    let mean-parents mean born-length-parents
    let var-parents variance born-length-parents
    let num-crossover (floor (count spawners / 2))
    ;; polygamous mating with satellite males (not in good condition)
    repeat num-crossover
    [
      let num-males 1 + random 4 ; number of males drawn randomly from an uniform distribution from 1 to 4
      let all-parent-M spawners with [ sex = "M" ]
      if count all-parent-M < num-males [ stop ]
      let no-parent-M max-n-of num-males spawners with [ sex = "M" ] [condition-factor]
      let sel-parent-M all-parent-M with [ not member? self no-parent-M and not spawned? ]
      if count spawners with [ sex = "F" and not spawned? ] <= 1 [ stop ]
      if count sel-parent-M < num-males [ stop ]
      ;; select the parents: first, the spawners that have moved to spawn, then the other spawners
      let parent-M n-of num-males sel-parent-M
      let parent-F max-one-of spawners with [ sex = "F" and not spawned? ] [condition-factor]
      if (count spawners with [ sex = "M" and not spawned? and moved-to-spawn? ] - num-males) >= num-males
      [
        if any? spawners with [ sex = "M" and not spawned? and moved-to-spawn? ]
        [
          set all-parent-M spawners with [ sex = "M" and moved-to-spawn? ]
          set no-parent-M max-n-of num-males spawners with [ sex = "M" and moved-to-spawn? ] [condition-factor]
          set sel-parent-M all-parent-M with [ not member? self no-parent-M and not spawned? ]
          set parent-M n-of num-males sel-parent-M
        ]
      ]
      if any? spawners with [ sex = "F" and not spawned? and moved-to-spawn?]
      [ set parent-F max-one-of spawners with [ sex = "F" and not spawned? and moved-to-spawn?] [condition-factor] ]
      ;; length deviances of parents M and F from mean-parents
      let dummy VBLF-reverse parent-M
      let dev-M 0
      let temp (random-normal meanl-birth-C sdl-birth-C)
      if temp < trdown-C [set temp trdown-C]
      if temp > trup-C [set temp trup-C]
      if length dummy = 0 [ set dev-M (mean-parents - temp) ]
      if length dummy = 1 [ set dev-M (mean-parents - (item 0 dummy)) ]
      if length dummy > 1 [ set dev-M (mean-parents - mean dummy) ]
      let dev-F (mean-parents - (VBLF-reverse parent-F))
      ask parent-F
      [
        set spawned? true
        set status "spawner"
        set xcor 1
        let num-fry update-num-offspringC [body-length] of parent-F
        hatch-trout num-fry
        [
          set hidden? true ;; hide trout until hatching
          set age -1 set stage "fry"
          ; genotype of parent-M is a mixture of the several genotypes of males
          let genotype-mix mixture ([genotype] of parent-M)
          ;; define genotypes for eggs
          let egg-genotype cross-genotype (genotype-mix) ([genotype] of parent-F)
          set genotype egg-genotype
          set xcor 1
          set current-stream "C"
          set natal-stream "C"
          set num-offspring 0
          set week-of-birth week-of-year
          set week-of-birth2 (week + 1)
          ifelse random-float 1 > 0.5 [ set sex "M" ] [ set sex "F" ]
          set status "non-spawner" set spawned? false
          set moved-to-spawn? false set returned? false
          ;; set body-length as function of parents' length and environment
          let genetic-dev (sqrt length-heritability) * (dev-M + dev-F)
          let envi-var ((1 - length-heritability) ^ 2) * var-parents
          let envi-dev random-normal 0 (sqrt envi-var)
          set body-length mean-parents + genetic-dev + envi-dev
          let temp2 (random-normal meanl-birth-C sdl-birth-C)
          if temp2 < trdown-C [set temp2 trdown-C]
          if temp2 > trup-C [set temp2 trup-C]
          if body-length < trdown-C or body-length > trup-C [ set body-length temp2 ]
          ;; set body-weight and condition-factor
          set condition-factor (random-normal mean-bcf-C sd-bcf-C)
          set body-weight (condition-factor * ((body-length) ^ 3) / 100000)
        ]
        set num-offspring num-fry
      ]
      ask parent-M
      [
        ;set spawned? true ;; shut because males can reproduce more than once
        set status "spawner"
        set xcor 1
        set num-offspring [num-offspring] of parent-F
      ]
    ]
  ]
end

to trout-spawn-in-streamL
  let spawners trout with [ status = "candidate-spawner" or status = "spawner" and current-stream = "L" ]
  ifelse count spawners < 2
  [ stop ]
  [
    let born-length-parents VBLF-reverse spawners
    ;; mean and variance of length of parents when born
    if length born-length-parents < 2 [ stop ]
    let mean-parents mean born-length-parents
    let var-parents variance born-length-parents
    let num-crossover (floor (count spawners / 2))
    ;; polygamous mating with satellite males (not in good condition)
    repeat num-crossover
    [
      let num-males 1 + random 4 ; number of males drawn randomly from an uniform distribution from 1 to 4
      let all-parent-M spawners with [ sex = "M" ]
      if count all-parent-M < num-males [ stop ]
      let no-parent-M max-n-of num-males spawners with [ sex = "M" ] [condition-factor]
      let sel-parent-M all-parent-M with [ not member? self no-parent-M and not spawned? ]
      if count spawners with [ sex = "F" and not spawned? ] <= 1 [ stop ]
      if count sel-parent-M < num-males [ stop ]
      ;; select the parents: first, the spawners that have moved to spawn, then the other spawners
      let parent-M n-of num-males sel-parent-M
      let parent-F max-one-of spawners with [ sex = "F" and not spawned? ] [condition-factor]
      if (count spawners with [ sex = "M" and not spawned? and moved-to-spawn? ] - num-males) >= num-males
      [
        if any? spawners with [ sex = "M" and not spawned? and moved-to-spawn? ]
        [
          set all-parent-M spawners with [ sex = "M" and moved-to-spawn? ]
          set no-parent-M max-n-of num-males spawners with [ sex = "M" and moved-to-spawn? ] [condition-factor]
          set sel-parent-M all-parent-M with [ not member? self no-parent-M and not spawned? ]
          set parent-M n-of num-males sel-parent-M
        ]
      ]
      if any? spawners with [ sex = "F" and not spawned? and moved-to-spawn?]
      [ set parent-F max-one-of spawners with [ sex = "F" and not spawned? and moved-to-spawn?] [condition-factor] ]
      ;; length deviances of parents M and F from mean-parents
      let dummy VBLF-reverse parent-M
      let dev-M 0
      let temp (random-normal meanl-birth-L sdl-birth-L)
      if temp < trdown-L [set temp trdown-L]
      if temp > trup-L [set temp trup-L]
      if length dummy = 0 [ set dev-M (mean-parents - temp) ]
      if length dummy = 1 [ set dev-M (mean-parents - (item 0 dummy)) ]
      if length dummy > 1 [ set dev-M (mean-parents - mean dummy) ]
      let dev-F (mean-parents - (VBLF-reverse parent-F))
      ask parent-F
      [
        set spawned? true
        set status "spawner"
        set xcor 0
        let num-fry update-num-offspringL [body-length] of parent-F
        hatch-trout num-fry
        [
          set hidden? true ;; hide trout until hatching
          set age -1 set stage "fry"
          ; genotype of parent-M is a mixture of the several genotypes of males
          let genotype-mix mixture ([genotype] of parent-M)
          ;; define genotypes for eggs
          let egg-genotype cross-genotype (genotype-mix) ([genotype] of parent-F)
          set genotype egg-genotype
          set xcor 0
          set current-stream "L"
          set natal-stream "L"
          set num-offspring 0
          set week-of-birth week-of-year
          set week-of-birth2 (week + 1)
          ifelse random-float 1 > 0.5 [ set sex "M" ] [ set sex "F" ]
          set status "non-spawner" set spawned? false
          set moved-to-spawn? false set returned? false
          ;; set body-length as function of parents' length and environment
          let genetic-dev (sqrt length-heritability) * (dev-M + dev-F)
          let envi-var ((1 - length-heritability) ^ 2) * var-parents
          let envi-dev random-normal 0 (sqrt envi-var)
          set body-length mean-parents + genetic-dev + envi-dev
          let temp2 (random-normal meanl-birth-L sdl-birth-L)
          if temp2 < trdown-L [set temp2 trdown-L]
          if temp2 > trup-L [set temp2 trup-L]
          if body-length < trdown-L or body-length > trup-L [ set body-length temp2 ]
          ;; set body-weight and condition-factor
          set condition-factor (random-normal mean-bcf-L sd-bcf-L)
          set body-weight (condition-factor * ((body-length) ^ 3) / 100000)
        ]
        set num-offspring num-fry
      ]
      ask parent-M
      [
        ;set spawned? true ;; shut because males can reproduce more than once
        set status "spawner"
        set xcor 0
        set num-offspring [num-offspring] of parent-F
      ]
    ]
  ]
end

;; stream C

to-report update-num-offspringC [ female-length ] ;; linear function
  ;; compute the intermediate variables for the linear offspring production function for trout of stream C
  set offspringC-varA (offprodC-max - offprod-min) / (offprod-max-length - offprod-min-length)
  set offspringC-varB offprod-min - (offspringC-varA * offprod-min-length)
  report ((offspringC-varA * female-length) + offspringC-varB)
end

;; stream L

to-report update-num-offspringL [ female-length ] ;; linear function
  ;; compute the intermediate variables for the linear offspring production function  for trout of stream C
  set offspringL-varA (offprodL-max - offprod-min) / (offprod-max-length - offprod-min-length)
  set offspringL-varB offprod-min - (offspringL-varA * offprod-min-length)
  report ((offspringL-varA * female-length) + offspringL-varB)
end

to-report cross-genotype [ genotype1 genotype2 ]
  let new-genotype []
  let bit 0
  repeat length genotype1
  [
    let choice random 4
    if choice = 0
    [ set new-genotype (lput (word(substring (item bit genotype1) 0 4)(substring (item bit genotype2) 0 3)) new-genotype)]
    if choice = 1
    [ set new-genotype (lput (word(substring (item bit genotype1) 0 3) (substring (item bit genotype2) 3 7)) new-genotype)]
    if choice = 2
    [ set new-genotype (lput (word(substring (item bit genotype2) 0 3) (substring (item bit genotype1) 3 7)) new-genotype)]
    if choice = 3
    [ set new-genotype (lput (word(substring (item bit genotype1) 4 7) (substring (item bit genotype2) 3 7)) new-genotype)]
    set bit bit + 1
  ]
  report new-genotype
end

to-report mixture [ genotype-temp ]
  let genotype-mix []
  let bit 0
  repeat length one-of genotype-temp
  [
    let choice random (length genotype-temp) ; choose randomly one genotype among n males
    set genotype-mix lput item bit (item choice genotype-temp) genotype-mix
    set bit bit + 1
  ]
  report genotype-mix
end

to-report VBLF-reverse [ trout-indiv ]
  ifelse is-agentset? trout-indiv
  [
    let length-when-born []
    (foreach sort trout-indiv
      [
        let time 0
        let length-diff 0
        let length-when-born-temp 0
        ask ?
        [
          set time (week - week-of-birth2)
          ifelse natal-stream = "C"
          [
            set length-diff (streamC-max-length - body-length)
            set length-when-born-temp (streamC-max-length - (length-diff / ((1 - streamC-parK) ^ (time))))
          ]
          [
            set length-diff (streamL-max-length - body-length)
            set length-when-born-temp (streamL-max-length - (length-diff / ((1 - streamL-parK) ^ (time))))
          ]
        ]
        set length-when-born lput length-when-born-temp length-when-born
      ])
    report length-when-born
  ]
  [
    let time (week - ([week-of-birth2] of trout-indiv))
    ifelse [natal-stream] of trout-indiv = "C"
    [
      let length-when-born (streamC-max-length - ((streamC-max-length - [body-length] of trout-indiv) / ((1 - streamC-parK) ^ (time))))
      report length-when-born
    ]
    [
      let length-when-born (streamL-max-length - ((streamL-max-length - [body-length] of trout-indiv) / ((1 - streamL-parK) ^ (time))))
      report length-when-born
    ]
  ]
end

to trout-become-candidate-migrants
  if (age = move-min-age or age = move-max-age) and current-stream = "C" and natal-stream = "C"
  [ if random-normal move-mean-length move-sd-length < body-length
    [ set status "candidate-migrant" ] ]
end

;; movement from C to L

to trout-move-downstream
  let temperature-streamC [temperature] of one-of patches with [ stream = "C" ]
  let flow-streamC [flow] of one-of patches with [ stream = "C" ]
  if status = "candidate-migrant"
  [ if random-normal move-mean-temperature move-sd-temperature < temperature-streamC
    and random-lognormal move-mean-flow move-sd-flow < flow-streamC
    [ ifelse age = 1
      ;; juveniles age 1
      [ if random-float 1 < move-age1-prob
        [ set xcor 0 set current-stream "L" set status "migrant" ] ]
      ;; juveniles age 2
      [ if random-float 1 < move-age2-prob
        [ set xcor 0 set current-stream "L" set status "migrant" ] ]
    ]
  ]
end

to update-move-age1-prob ;; logistic function
  let nb1 count trout with [current-stream = "C" and body-length > 70]
  let Z1 (exp((move-age1-varA * nb1) + move-age1-varB))
  set move-age1-prob (Z1 / (1 + Z1))
end

to update-move-age2-prob ;; logistic function
  let nb2 count trout with [current-stream = "C" and body-length > 70]
  let Z1 (exp((move-age2-varA * nb2) + move-age2-varB))
  set move-age2-prob (Z1 / (1 + Z1))
end

to trout-move-back
  ;; candidate spawners return to previous stream
  if (status = "candidate-spawner" and current-stream = "C" and moved-to-spawn?)
  ;; effective spawners return to previous stream
    or (status = "spawner" and current-stream = "C" and moved-to-spawn?)
  [ set current-stream "L" set xcor 0 set returned? true ]
end

to leave-streamL
  set breed gone
  hide-turtle
end

;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

to-report random-lognormal [mu sigma]
  let S sqrt(ln(((sigma / mu) ^ 2) + 1))
  let M ln (mu) - ((S ^ 2) / 2)
  report exp(random-normal M S)
end
